When we talk about vehicle tracking and immobilizer systems, many people focus only on the GPS tracker, the monitoring platform, or the application used. However, there is an extremely important component for the reliability of the entire system: the automotive relay responsible for vehicle immobilization.

Although it is a relatively small and low-cost component, the relay is responsible for interrupting or re-establishing the electrical supply to certain vehicle circuits, allowing immobilization to be carried out safely and efficiently.

The choice of an inadequate relay can result in operational failures, overheating, locking, loss of immobilization, and even damage to the vehicle's electrical installation.

In this article, you will understand which technical characteristics truly matter when choosing a good automotive relay for vehicle immobilization, both in 12 Volt and 24 Volt vehicles.

What is an automotive relay?

An automotive relay is an electromechanical switch controlled electrically.

Its operation is relatively simple:

• A small electric current energizes a coil;
• The coil creates a magnetic field;
• This field moves a metallic armature;
• The internal contacts close or open a higher power circuit.

In practice, this allows a tracker, which operates with low electrical current, to control circuits that power important vehicle components.

It is precisely this process that makes it possible to perform remote vehicle immobilization safely.

What is the function of the relay in vehicle immobilization?

In tracking systems, the relay is normally used to interrupt circuits such as:

• Fuel pump power supply;
• Ignition circuit;
• Starter motor solenoid;
• Other circuits authorized by the vehicle manufacturer.

The relay acts as an intermediary between the tracker and the vehicle's electrical circuit.

Therefore, it needs to withstand thousands of activations during its lifespan without failures.

Why does relay quality make such a difference?

Many installers end up purchasing relays based solely on price.

This is one of the biggest mistakes that can compromise the entire reliability of the system.

Low-quality relays typically exhibit:

• Fragile internal contacts;
• Premature oxidation;
• Low current capacity;
• Poorly executed solders;
• Coils with low efficiency;
• Plastics with low thermal resistance;
• Loss of contact pressure;
• Overheating.

All of this significantly increases the possibility of immobilization failures.

In some cases, the relay may remain permanently closed or open, making the system totally inefficient.

The importance of materials used in manufacturing

A superior quality automotive relay uses carefully selected materials to withstand years of operation.

Among them are:

Electrical contacts

Contacts are responsible for conducting current.

The best manufacturers use metal alloys composed of:

• Silver;
• Silver-tin;
• Silver-nickel;
• Silver-cadmium (in specific applications).

These materials exhibit:

• Lower electrical resistance;
• Less heating;
• Greater resistance to electrical arc;
• Longer lifespan.

Low-quality relays, on the other hand, use simpler metals that wear out quickly.

Electromagnetic coil

The coil is responsible for the actuation force.

It must have:

• High-purity copper wire;
• Temperature-resistant insulation;
• Uniform winding;
• Electrical resistance within specifications.

Poorly manufactured coils can overheat excessively, consume more current, and drastically reduce the component's lifespan.

Housing

The housing must withstand:

• Constant vibrations;
• Humidity;
• High temperatures;
• Dust;
• Chemical vapors present in the engine compartment.

Relays of good origin use engineering polymers resistant to heat and deformation.

Terminals

Terminals need to have:

• Good thickness;
• Excellent anti-corrosion treatment;
• High mechanical resistance.

Thin terminals tend to heat more and can cause poor contact.

The difference between 12V and 24V relays

Although externally they look practically the same, there are important differences between models intended for 12V and 24V systems.

12V Relay

Used in:

• Cars;
• SUVs;
• Light pickup trucks;
• Motorcycles;
• Light utility vehicles.

Its coil is designed to operate with approximately 12 Volts.

Applying 24V to a 12V relay typically causes immediate coil burnout.

24V Relay

Used in:

• Trucks;
• Buses;
• Agricultural machinery;
• Tractors;
• Heavy equipment.

Its coil was specifically developed for 24V electrical systems.

If powered with only 12V, it typically will not have enough force to actuate.

Current capacity is fundamental

Another extremely important point is to observe the current supported by the contacts.

It is common to find relays classified as:

• 20A;
• 30A;
• 40A;
• 50A;
• 70A.

However, this current does not always represent the real capacity in continuous operation.

Recognized manufacturers conduct tests following international standards and clearly state:

• Nominal current;
• Maximum current;
• Peak current;
• Electrical life;
• Mechanical life.

Generic products often have optimistic specifications that do not reflect actual performance.

The problem of electrical arcing

Every time a relay interrupts an electrical current, a small electrical arc forms between the contacts.

This arc generates:

• Heat;
• Wear;
• Carbonization;
• Increased electrical resistance.

The better the material used in the contacts, the less this wear will be.

That is why quality relays have a significantly longer lifespan.

Vibration: a constant challenge

Vehicles are subjected daily to:

• Potholes;
• Dirt roads;
• Engine vibration;
• Impacts;
• Sudden temperature changes.

The relay must continue to operate perfectly even under these conditions.

First-line manufacturers conduct specific tests for:

• Vibration;
• Mechanical impact;
• Thermal resistance;
• Actuation cycles.

Operating temperature

In the engine compartment, temperatures above 90°C are common.

Professional automotive relays are developed to operate in ranges that typically vary between:

• -40°C to +125°C, depending on the manufacturer.

Low-quality relays tend to deform internally when subjected to high temperatures.

Component lifespan

A quality automotive relay can withstand hundreds of thousands of actuations.

In many models from traditional manufacturers, the mechanical lifespan exceeds:

• 1 million cycles.

Electrical life, however, depends directly on the activated load.

The higher the current, the greater the wear on the contacts.

Certifications also matter

Whenever possible, prefer components produced by manufacturers that follow international standards, such as:

• ISO 9001;
• IATF 16949 (automotive sector);
• RoHS;
• CE, when applicable.

These certifications indicate more controlled and consistent production processes.

Penny wise, pound foolish

In a vehicle immobilization system, saving a few dollars on the purchase of a relay can represent much greater financial loss in the future.

A defective relay can cause:

• Immobilization failures;
• Return of stolen vehicle without possibility of interruption;
• Electrical breakdowns;
• Increased maintenance costs;
• Loss of credibility for the installing company.

For tracking companies, choosing reliable components means not only greater durability but also reduced technical calls, lower warranty claims, and greater customer satisfaction.

How to choose a good relay for vehicle immobilization?

Before purchasing, check:

• Correct voltage (12V or 24V);
• Real current capacity;
• Quality of internal contacts;
• Recognized manufacturer;
• Vibration resistance;
• Operating temperature;
• Certifications;
• Terminal finish;
• Housing quality;
• Complete technical specifications.

Avoid unbranded products, those without a technical data sheet, or without any information about tests and certifications.

Conclusion

The relay is one of the most important components of a vehicle immobilization system. Despite its small size, it plays a critical role in the safety and reliability of the installation.

Opting for a high-quality relay means investing in greater durability, lower failure rates, greater user safety, and better performance of the tracking system.

Whether in 12V or 24V vehicles, the correct choice must consider much more than price. Materials used in manufacturing, current capacity, thermal resistance, contact quality, certifications, and manufacturer reputation are factors that make all the difference in the equipment's lifespan.

When it comes to vehicle safety, quality components are not an additional cost: they are an indispensable investment.

Frequently Asked Questions (FAQ)

What is the difference between a 12V and a 24V relay?

The main difference lies in the coil's supply voltage. A 12V relay should be used in vehicles with a 12-volt electrical system, while a 24V relay is intended for trucks, buses, and heavy machinery.

Can I use a 12V relay in a 24V truck?

No. Powering a 12V relay with 24V can permanently damage the coil and compromise the system's operation.

Is a more expensive relay really worth it?

Yes. Relays from recognized manufacturers use superior materials, have a longer lifespan, better withstand vibrations, high temperatures, and have a lower failure rate.

Does the relay affect the safety of vehicle immobilization?

Yes. A low-quality relay can fail during actuation, prevent vehicle immobilization, or cause unexpected interruptions, compromising the system's reliability.

What current is recommended for an immobilizer relay?

It depends on the circuit to be interrupted. It is essential to respect the nominal current specified by the manufacturer and maintain an adequate safety margin to avoid overheating and premature wear.
